APPLICATION
- This connector is used to connect different sections of aluminum wires (uncoated) that do not include mechanical tension. This clamp is used to install the aerial bundled cable on the pole with a suspension clamp or dead-end clamp.
TECHNICAL SPECIFICATIONS
| Model | Cross section of main and sub branch aluminum cable | Tightening torque of bolt | Other features |
| PGC 10 | AL 16-95 (without cable holder)
AL 6-95 (with cable holder) |
20±1 Nm | Single bolt |
PARTS AND OMPONENTS
| Body | Corrosion resistant aluminum alloy with high conductivity and electrical resistance with tin and copper plating. |
| Bolt and washer |
Galvanized steel |
INSTALLATION METHOD
First, separate the upper and lower sides then place the aerial bundled cable sections in the cable passage, then hold the clamp in the designed place in the connector wrench, and then tighten the bolt to the appropriate torque.
PACKAGING WITHOUT PLASTIC COVER
110 PCS/CTN
